Gas & Petrochemical Online Courses
Here's every CFD online course related to Gas & Petrochemical category.
Evaluation of NO and Soot Emissions from Wood Gas Flare, ANSYS Fluent
Intermediate, Advanced
Price: $140
The problem numerically simulates Evaluation of NO and Soot Emissions from Wood Gas Flare using ANSYS Fluent software. We design the 3-D model with the SpaceClaim software. We Mesh the model with ANSYS Meshing software, and the element number equals 2.8 millions. Energy and species transport models were enabled to account for heat transfer and chemical reactions.
Price: $10
In this project, the flow inside a coil is modeled using ANSYS Fluent software. The geometry was created in Design Modeler, and a mesh consisting of 4,824,847 elements was generated using ANSYS Meshing. In this project we are going to find the outlet temperature and calculate the static pressure and static temperature throughout the domain.
Price: $240
In this project, a Circulating Fluidized Bed(CFB) Boiler is simulated using ANSYS Fluent software. The 3-D geometry is designed in spaceclaim then meshed in ANSYS Meshing producing 437,472 unstructured cells. The species transport including volumetric reactions, is taken into account for modeling combustion. The DPM model is used to model the particles.
Price: $48
⦁ This problem simulates Bubble Columns Reactor using the VOF model in Ansys Fluent software. ⦁ The 2-D geometry is designed in Design Modeler software. ⦁ ANSYS Meshing software is used to generate the mesh; the element number equals 93,687. ⦁ In this project, the rising of air bubbles is simulated using the VOF model.
Mixing Pipe, Baffle Configuration Effect on Mixing, CFD Simulation
Beginner, Intermediate
Price: $12
The problem numerically simulates a mixing pipe, baffle configuration effect on mixing in ANSYS Fluent software. The 3D geometry of the model is created in SpaceClaim software. The model is meshed in ANSYS Meshing creating structural mesh with 1,330,000 , 1,380,000 and 1,500,000 elements for the different cases. The K-ω SST model is used to describe turbulence of the flow.
Rotary Heat Exchanger, Effect of Mass Flow Rate CFD Simulation
Beginner, Intermediate
Price: $12
The problem numerically simulates a Rotary Heat Exchanger, Effect of Mass Flow Rate on heat transfer coefficient in ANSYS Fluent software. The 2D geometry of the model is created in Design Modeler software. The model is meshed in ANSYS Meshing creating 86,598 elements. The Standard k-epsilon model is used to describe turbulency of the flow.
Steam Ejector with Gas Methane Fluid CFD simulation, ANSYS Fluent
Intermediate, Advanced
Price: $12
The problem numerically simulates a Steam Ejector with Gas Methane Fluid in ANSYS Fluent software. The 2D geometry of the model is created in Design Modeler software. The model is meshed in ANSYS Meshing creating 11,132 elements. We simulate the problem via Density-based solver to define Compressible flow.
Price: $20
The present problem simulates the pipeline pigging using ANSYS Fluent software. We have designed the geometry using Spaceclaim software and created the mesh on this geometry using ANSYS Meshing software. The mesh type is unstructured with 659,988 cells. The Dynamic Mesh method is used to simulate the motion of pigging into the pipes Remeshing and Smoothing sub-models took over the deforming and regenerating of elements
Delta T Macro UDF, Time Step Control CFD Simulation
Intermediate, Advanced
Price: $180
The problem numerically simulates the water filling in the tank using ANSYS Fluent software. We design the 2-D model with the Design Modeler software. We mesh the model with ANSYS Meshing software, and the element number equals 135996. We performed the simulation in a Transient (unsteady state). We use the VOF Multiphase model to define water and air. We use the User-Defined Function (UDF) to control time step size. We use the DELTAT Macro for UDF.
