FSI Online Courses

Price: $15

This study investigates the displacement of a net panel subjected to water flow using ANSYS Fluent simulation. The geometry of a square net panel was created using ANSYS Design Modeler. The computational domain was then discretized using ANSYS Meshing, resulting in over 2,339,853 elements. The simulation aims to analyze the net panel's fluid-structure interaction The structural model utilized a Linear Elasticity submodel to simulate the net panel’s deformation

Price: $649

This study presents a Fluid-Structure Interaction (FSI) simulation of a quadcopter using ANSYS Fluent The quadcopter geometry was created using ANSYS SpaceClaim The model was then meshed using ANSYS Meshing, which generated an unstructured mesh consisting of approximately 499,152 elements To accurately capture the blades’ rotation, two frame motion(MRF) zones are applied to the blades. The Structure model with the Linear Elasticity option was enabled to investigate the displacement of the blade

Price: $360

The study conducts a CFD analysis of aortic valve displacement using ANSYS Workbench. The geometry is designed in SpaceClaim based on CT-scan data, with a mesh of 67,926 fluid elements and 627,914 solid elements. The simulation uses a pressure-based transient solver with a laminar flow model. System coupling between Transient Structural and Fluent enables analysis of valve leaflet movement and blood flow interaction. Results show pressure gradients, velocity patterns, wall shear stress distribution, and valve leaflet deformation.

Price: $30

The problem numerically simulates the Fluid-Structure Interaction over Vertical Turbine using ANSYS Fluent software. We designed the 3-D model using the Design Modeler software. The mesh grid is generated using ANSYS Meshing, and the element number equals 705,465. The Frame Motion method is used to rotate the turbine. FSI model analyses total strain, and stress over the VAWT turbine.

Price: $489

The problem numerically simulates the Fluid-Structure Interaction over Northrop Grumman RQ-4 Global Hawk using ANSYS Fluent software. The Global Hawk geometry was modeled using SpaceClaim and then imported into ANSYS meshing for meshing consisting of 5,056,067 non-conformal elements. The simulation used a pressure-based solver. One way FSI model analyses total strain, and stress over the turbine.

Price: $15

This project simulates the Fluid-Structure Interaction (FSI) of a high-speed airfoil using ANSYS Fluent software. The airfoil geometry is designed in ANSYS Design Modeler. ANSYS Meshing is used to generate a high-quality mesh with 2,398,833 elements. In this study, the complex flow behavior and structural response of the airfoil are simulated using a pressure-based transient solver and the Realizable k-epsilon turbulence model. The pressure distribution, velocity patterns, and airfoil displacement under high-speed conditions are well modeled in this project.

Price: Free

What are FSI and its appliance? 1-way FSI 2-way FSI

Price: $54

The problem numerically simulates the Fluid-Structure Interaction over HAWT Turbine using ANSYS Fluent software. We design the 3-D model by the Design Modeler software. Mesh grid is generated using ANSYS Meshing , and the element number equals 3,465,821. The MRF method is used to rotate the turbine. FSI model analyses total strain, and stress over the turbine.

Price: $42

The problem numerically simulates Centrifugal Pump using ANSYS Fluent software. We design the 3-D model by the Design Modeler software. We Mesh the model by ANSYS Meshing software, and the element number equals 3649835. We use the Frame Motion to define the rotational movement. we use the fluid structure Interaction (FSI)
