Everything About Discrete Phase Model (DPM) In ANSYS FLUENT

In this video which is the 2nd chapter of the DPM Training Course, we get into ANSYS Fluent software and explain almost every section of the Discrete Phase Model (DPM) Module. It has been tried to investigate various available models. This chapter summarizes the following subjects:

• Discrete Phase Model Dialog Box: Interaction, Particle Treatment
• Tracking parameters
• Physical Models: Particle Radiation Interaction, Thermophoretic force, Saffman Lift force, Virtual mass force, Pressure gradient force, Erosion/Accretion, Pressure-dependent boiling, Temperature dependant latent heat, Two-way turbulence coupling, DEM collision, Stochastic collision, Coalescence, Breakup,
• Injection Dialog Box
• Injection Type: Single, Group, Surface, Cone
• Injection Particle Type: Massless, Inert, Droplet, Combusting, Multi-component
• Diameter Distribution: Linear, Uniform, Rosin-rammler, Rosin-rammler logarythmic
• Drag laws: Spherical, Non-spherical, Stokes-cunningham, High-Mach-number, Dynamic drag
• Breakup Models: TAB, Wave
• Turbulent Dispersion: Stochastic tracking, Cloud tracking
• Parcel
• DPM Boundary Condition: Reflect, Trap, Escape, Wall-jet, Wall-film
