VOF Online Courses

Price: $24

The present problem simulates the water flow inside a Turgo water turbine by ANSYS Fluent software. The geometry is designed using Design Modeler software. The meshing of the model has been done using ANSYS Meshing software and the element number is 4,344,106. Mesh Motion (Sliding Mesh) is used to define the rotation of the blades inside the chamber.

Price: $180

The problem numerically simulates the water filling in the tank using ANSYS Fluent software. We design the 2-D model with the Design Modeler software. We mesh the model with ANSYS Meshing software, and the element number equals 135996. We performed the simulation in a Transient (unsteady state). We use the VOF Multiphase model to define water and air. We use the User-Defined Function (UDF) to control time step size. We use the DELTAT Macro for UDF.

Price: $240

The problem numerically simulates the evaporation and condensation using ANSYS Fluent software. We design the 3-D model with the Design Modeler software. We mesh the model with ANSYS Meshing software; the element number equals 1,574,100. We use the VOF Multiphase model to define water, liquid, and vapor. We define a Mass Transfer between water liquid and water vapor. We use the User-Defined Function (UDF) to define a mass transfer (evaporation and condensation). We use the Mass-Transfer Macro for UDF.

Price: $220

This project numerically simulates the Hydro-Abrasive Erosion in Pelton Turbine using ANSYS Fluent software. The 3-D geometry is designed in Design Modeler software. We used ANSYS Meshing Software to generate mesh; the element number equals 6,433,121. The multiphase VOF model simulates the water jet. The 2-way DPM model also enables the erosion of the solution. The rotational movement of the turbine is modeled using Mesh Motion Approach.

Price: $160

The problem numerically simulates the Water Jets Impingement using ANSYS Fluent software. The 3-D geometry is designed in Design Modeler software. We used ANSYS Meshing to generate mesh; the element number equals 72,000. The Automatic Mesh Adaptation is the mesh method for this problem. The liquid bulk in the domain is simulated using VOF model. Also, the droplets are modeled via DPM model.

Price: $24

The problem numerically simulates the Check Valve using ANSYS Fluent software. We design the 2-D model with the Design Modeler software. We mesh the model with ANSYS Meshing software, and the element number equals 14,586. We perform this simulation as unsteady (Transient). We use the Dynamic Mesh Model to define deforming and moving zones. We use the 6-DOF solver to define the rotational motion of the valve. We use the VOF Multiphase Model to define the air and water. We use the Execute Command to define the interruption of the input flow.

Price: $160

The current CFD Analysis simulates the Color Spray Gun with Wall Film via ANSYS Fluent software. We have designed the initial geometry using ANSYS Design Modeler software and created the mesh on this geometry using ANSYS Meshing software. The mesh type is tetrahedral with 560,134 cells. VOF multiphase model, along with the Discrete Phase Model, is used. The liquid wall film boundary condition is also enabled over the painted wall. The Automatic Mesh Adaptation option is used to enhance the quality of the mesh. The solution is Transient.

Price: Free

Overview of Multiphase flows Classification of Multiphase flows Multiphase flow regimes Eulerian-Lagrangian vs. Eulerian-Eulerian approaches VOF model and its applications Eulerian model and its applications Mixture model and its applications Choosing among Eulerian, Mixture, and VOF Summary

Price: Free

Introduction Mixture model Wet steam model Summary
